3.0V Li-MnO2 batteries
3.0V Li-MnO2 batteries
Product features
Product description
Lithium manganese dioxide cells have a metallic lithium cathode (the lightest of all the metals) and a solid manganese dioxide anode, immersed in a non-corrosive, non-toxic organic electrolyte. They deliver a nominal voltage of 3V and are cylindrical in shape, with spiral electrodes.
Key Feature
High and Stable operating voltage
Wide Operating Temperature Range:
Cylindrical battery: -40℃~85℃; Coin Battery: -20℃~70℃，TPMS: -40℃~125℃.
High Energy Density
Low self-discharge rate:(less than≤2% per year at 20℃),
UL recognized
UN recognized
RoHS compliance
Technical parameter
| Model | Norminal Capacity | Norminal Voltage | Cell Demensions(mm) | Internal Resistance(omh) |
Approximate weight(g) |
||
|---|---|---|---|---|---|---|---|
| mAh | v | Thickness | Width | Length | |||
| HJL-CR34615E | 12000 | 3.0 | _ | 34.0 | 61.5 | _ | 125 |
| HJL-CR26500E | 5000 | 3.0 | _ | 26.2 | 50.5 | _ | 55 |
| HJL-CR17505E | 2400 | 3.0 | _ | 17.0 | 50.5 | _ | 30 |
| HJL-CR17450E | 2200 | 3.0 | _ | 17.0 | 50.5 | _ | 26 |
| HJL-CR14505E | 1400 | 3.0 | _ | 14.5 | 50.5 | _ | 17 |
| HJL-CR123A | 1500 | 3.0 | _ | 17.0 | 34.5 | _ | 16 |
| HJL-CR-P2 | 1500 | 6.0 | _ | 35.0 | 19.5 | _ | 42 |
| HJL-2CR5 | 1500 | 6.0 | _ | 35.0 | 19.5 | _ | 38 |
| HJL-CR14250H | 800 | 3.0 | _ | 17.0 | 34.0 | _ | 12 |
| HJL-CR14250E | 650 | 3.0 | _ | 14.5 | 25.2 | _ | 8.5 |
